4 Renk 45 Cm Packing Tape Flexo Printing Machine

Our 4 Color, 45 cm duct tape flexo printing machine, which we call Sapphire, has been created with our advanced technology, good engineering, and quality materials. At this point, Safir, a machine that provides maximum benefit for our customers' long-term business models, is a pioneering model in its field.

Baskı Ünitesi/ Printing Units                                                4

Max. Material Genişlik/ Max. Material Width                    500 mm

Maksimum Baskı Genişliği/ Max. Printing Width               450 mm

Maksimum Bobin Çapı/ Max. Coil Entry Diameter            400 mm

Maksimum Sargı Çapı/ Max. Coil Output Diameter          300 mm

Minimum Baskı Uzunluğu/ Minimum Print Length           250 mm

Maksimum Baskı Uzunluğu/ Maximum Print Length        500 mm

Maksimum Mekanik Hız/ Max. Mechanical Speed            0-200 M./Dk.

Toplam Güç/ Total Power                                                    400V 50Hz 35kW 3 faz

Ana Motor Gücü/Main Engine Power                                 4 KW

Kurutma Sistemi/ Drying Sistem                                          Infrared + Fan

Makine Ağırlığı/Machine Weight                                        3.500 Kg

Makine Ölçüleri/ Machine Dimensions (LxWxH)               4.0 Mt. x 1.50 Mt. x 2.25 Mt.
